Sports LED Displays for Stadiums, Arenas and Sports Fields
LumiVue is a Gatineau company that designs and supplies sports LED displays for stadiums, arenas, sports centres, clubs and municipalities across Quebec and Ontario.
Perimeter advertising boards, scoreboards and big screens, built with cabinets made for outdoor use and impacts. Quoted on request.
What you can show
Perimeter advertising boards
Your sponsors' logos and videos all around the field. One LED board sells as many ad spots, rotating during the game.
Scoreboards and replays
Score, clock, replays and sponsor messages on the same screen.
Big screens for the crowd
Live camera, player introductions and entertainment between periods.
Sports centres and municipalities
Schedules, results and community messages at the entrance or above the stands.
The series
Every series services from the front or the rear and comes with a 3-year manufacturer warranty. Outdoor versions are protected against water and dust (IP65 or IP66). They are also built to use less power: in normal use, average consumption is about half of maximum consumption (published for the OF800-S, EV960-S and EX1600-S). Quoted by size, pixel pitch and structure.
MA960-S Series
Quoted on request
The most versatile. Hung, stacked or as a perimeter board, with cabinets that adjust in six directions. Soft masks and covers against impacts. A P4 indoor version is available.
- Pixel pitch
- Outdoor P5 to P10; indoor P4
- Cabinets
- 960 × 960 mm or 1280 × 960 mm
- Brightness
- Over 5,000 nits
- Water and dust
- IP65
- Energy
- Over 50% energy savings and a cabinet about 16 °C cooler, per the manufacturer
OF800-S Series
Quoted on request
Front service: the right series when the back of the screen can't be reached, against a wall or the stands. Soft mask, cushions and anti-collision design.
- Pixel pitch
- P6.25, P8.33 or P10
- Cabinets
- 800 × 900 mm, 98 mm thick, 22 kg
- Brightness
- 5,500 to 6,500 nits
- Water and dust
- IP65
- Energy
- Up to 30% savings; 300 W average per cabinet (600 W maximum)
- Lifetime
- 50,000 to 100,000 hours, depending on use
EV960-S Series
Quoted on request
3,840 Hz refresh rate, for a flicker-free picture on camera and on broadcast. Die-cast aluminium chassis, quick locks and protective cushion.
- Pixel pitch
- P6.67, P8 or P10
- Cabinets
- 960 × 960 mm, 87 mm thick, 25 kg
- Operating range
- −20 to +65 °C
- Water and dust
- IP66
- Energy
- 300 W average per cabinet (550 to 600 W maximum)
- Lifetime
- 50,000 hours
EX1600-S Series
Quoted on request
Built for the perimeter: a large, light cabinet, an adjustable back bracket and guides to line the board up. It runs from −40 to +60 °C.
- Pixel pitch
- P6.67, P8 or P10
- Cabinets
- 1600 × 960 mm
- Refresh rate
- 3,840 Hz and up
- Water and dust
- IP65
- Energy
- 350 to 400 W/m² average (800 W/m² maximum)
Manufacturer data. Exact specifications depend on the pixel pitch and version you choose, and are confirmed in your quote.
Frequently asked questions
Which series should I choose?
It depends on the location and how far the crowd sits. For a perimeter board, look at the EX1600-S or the MA960-S. If the back of the screen can't be reached, the OF800-S services from the front. For TV or streaming, the EV960-S offers 3,840 Hz. Tell us about your project and we'll suggest the series and pixel pitch.
Do these screens work in winter?
The EX1600-S Series is rated to run from −40 to +60 °C, and the EV960-S from −20 to +65 °C. We confirm the right series for your site in the quote.
How much does a sports LED display cost?
It's quoted on request: the price depends on size, pixel pitch, series and structure. We measure and send you a free quote.
Who handles installation?
LumiVue designs and supplies the display and handles commissioning. Structural or electrical work is done by a licensed contractor you deal with directly.
